As a BE developer, you’ve probably used JWTs (JSON Web Tokens) to authenticate users in APIs or microservices. But have you ever stopped to decode one and see what’s actually inside?

JWTs are more than just access tokens — they’re self-contained information carriers that hold user identity, claims, and security data. If you truly understand their structure, you’ll be able to:

Debug authentication issues quickly

Implement secure validation logic

Prevent token tampering or misuse

Build scalable, stateless APIs

In this post, we’ll dive deep into the three core parts of a JWT: Header, Payload, and Signature — and explore how they work together to make authentication both simple and powerful.

What Is the Structure of a JWT?

A JWT is a compact, URL-safe string that consists of three parts, separated by dots (.):

xxxxx.yyyyy.zzzzz

Each part is Base64Url encoded, which means you can safely include it in URLs, HTTP headers, or cookies without issues.

Here’s what each segment represents:

• Header — Describes the token’s type and the algorithm used for signing.
• Payload — Contains the actual claims (user data, roles, expiration time, etc.).
• Signature — Verifies that the token hasn’t been tampered with.

Let’s break them down one by one.

The Header — Token Type and Algorithm

The Header is a simple JSON object that defines metadata about the token.

A typical JWT header looks like this:

{
  "alg": "HS256",
  "typ": "JWT"
}

• alg: The signing algorithm (e.g., HS256 for HMAC-SHA256, RS256 for RSA).
• typ: The token type — always "JWT".

This part is then Base64Url encoded. For example, encoding the header above might give you something like:

eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9

Real-World Example Imagine your .NET API uses HS256 (HMAC-SHA256) with a secret key to sign tokens for your users. The Header tells any recipient of the token exactly how to verify it — using HMAC and your shared secret.

If you later switch to RS256 (public/private key), the Header will update accordingly, and the verification logic in your backend will adapt — no need to store sessions or extra metadata.

The Payload — The Token’s Data (Claims)

The Payload is the heart of a JWT. It contains claims — pieces of information about the user or the token itself.

Example Payload:

{
  "sub": "1234567890",
  "name": "Steve",
  "role": "admin",
  "iat": 1728124800,
  "exp": 1728128400
}

Let’s break these down:

JWT claims can be three types:

• Registered claims — standardized fields (iss, sub, aud, exp, iat)
• Public claims — custom fields you define (name, role, etc.)
• Private claims — app-specific claims shared between parties

After Base64Url encoding, the Payload may look like this:

eyJzdWIiOiIxMjM0NTY3ODkwIiwibmFtZSI6IlN0ZXZlIiwicm9sZSI6ImFkbWluIiwiaWF0IjoxNzI4MTI0ODAwLCJleHAiOjE3MjgxMjg0MDB9

The Signature — Ensuring Token Integrity

This is where the security magic happens.

The Signature ensures that the token hasn’t been altered since it was issued.

The formula is:

HMACSHA256(
    base64UrlEncode(header) + "." +
    base64UrlEncode(payload),
    secret)

If someone changes even one character in the Header or Payload, the Signature won’t match anymore, and the token will be rejected.

Example Signature (truncated):

SflKxwRJSMeKKF2QT4fwpMeJf36POk6yJV_adQssw5c

In a API, when a request includes a JWT in the Authorization header like:

Authorization: Bearer <token>

The framework (via JwtBearerHandler) automatically validates:

• The token’s Signature using the provided secret or public key
• The expiration time (exp)
• The issuer and audience if configured

If anything fails — boom 💥 — 401 Unauthorized.

Putting It All Together

Here’s what a full JWT looks like:

eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9.
eyJzdWIiOiIxMjM0NTY3ODkwIiwibmFtZSI6IlN0ZXZlIiwicm9sZSI6ImFkbWluIiwiaWF0IjoxNzI4MTI0ODAwLCJleHAiOjE3MjgxMjg0MDB9.
SflKxwRJSMeKKF2QT4fwpMeJf36POk6yJV_adQssw5c

Even though it looks like gibberish, every part has meaning:

• First part (Header): Algorithm and Type
• Second part (Payload): User Claims
• Third part (Signature): Verification Seal

You can decode the first two parts using jwt.io — just don’t share your secret key there!

Summary

Understanding the anatomy of a JWT is essential for writing secure and maintainable authentication logic in API.

• The Header defines the token type and signing algorithm.
• The Payload carries the user data (claims).
• The Signature guarantees integrity and authenticity.
